6 ft. R17D T12/HO LED Type A Plug & Play Replacement for 85W F72T12/HO

Plug & Play - T12 High-Output Fluorescent Tube Replacement - R17D Base

6 FT T12/HO/RDC waterproof LED directly relamps and replaces the 85 watt 72" fluorescent bulb F72T12/HO without rewiring or modification. It's a Plug and play product from our "Relamp Series" when switching to LED lighting. T12/HO bulb works with traditional magnetic ballasts and modern electronic ballasts for maximum convenience. Also fully compatible with Instant Start, Programmed Start, Rapid Start ballasts and legacy pre-heat magnetic ballasts.

Installing the lamp, as easy as changing a bulb:

1. Turn power OFF before installation
2. Remove the existing lamp
3. Install LED T12/HO
4. Switch on power

General Specifications:

• Energy saving of 51% from 85 watts to 42 watts with 4620 lumens output
• Energy saving of 36% from 85 watts to 54 watts with 5940 lumens output
• All plastic diffuser for better light distribution, less spot reflections
• O Rings to waterproof rotating caps and sealed diffuser for indoor and outdoor applications
• Heavy duty aluminum heat sink ensures the LED run cooler for longer
• Plastic and aluminum construction ensures less breakage
• Long life span of > 50,000+ hours
• High lumen output > 110 lumens/watt
• Available in 2700, 3000, 4100, 5000, 6000 Kelvin

• Uses 42,54 watts = 85 watts equivalent
• 2,3 bulbs per package
• Single Sided - 4620 lumens
• Dual Sided - 5940 lumens
• Nominal length 72-inch T12 (1-1.5inch diameter)

• Maximum overall length (M.O.L): Approx. 69.91” (1775.7 mm) with pins

• A.k.a T-12 High output Recessed Double Contact (RDC)
• Rotatable R17d end cap that swivels
• End cap can be adjusted regardless of socket orientation in the sign
• Special application lamps that are designed for cold weather
• Technical description: F72T12/HO, F72"T12/HO/RDC, High output T12 HO
• Suitable as Walk-in Cooler, Freezer and Refrigeration equipment lighting
• Ideal for vertical or horizontal installation, single-sided or double-sided signs

• Perfect for Gas stations, Signage, Billboards, cold weather
• Works with electronic and magnetic ballast only!
• Ballast operated lamp, not bypass compatible


Additional information:

• T12/HO LED lamp requires 4 wires connected. It's not compatible with 2 wires setup such as Allanson EESB ballasts
• Pictures of the gas price sign and company sign are installed with the relamp 3FT and 6FT Daylight T12/HO waterproof lamp. Pictures are taken and provided by our customers

Equivalent replacement for:

• F72T12/CW/HO
• F72T12/WW/HO
• F72T12/SP30/HO
• F72T12/SP35/HO
• F72T12/SP41/HO
• F72T12/SPX30/HO
• F72T12/SPX35/HO
• F72T12/CWX/HO
• F72T12/D/HO
• F72T12SGN/HO
• F72T12/N/HO
• F72T12/D830/HO
• F72T12/D835/HO
• F72T12/D30/HO
• F72T12/D35/HO
• F72T12/DSGN50/HO
• F72T12/GRO/HO/WS
• F72T12/SPEC30/HO
• F72T12/SPEC35/HO
• F72T12/SPEC41/HO
• F72T12/C50/HO

Why Plug & Play LED?

Simplicity for installer - The lamp snaps into the existing fixture without any wiring modifications, installation can be done by virtually anyone, as long as your existing ballast is compatible.

Safety - Whenever we can shorten the time someone has to spend dangling from a ladder, things are automatically safer.

No upfront cost - eliminate the need to hire a costly electrician to do modification.

Energy efficient - output on lamp is significantly improved with ballast for general consumption and commercial use.

Relamp LED products are designed and developed by New York LED Luminaries, Inc, Brooklyn, NY.
